Cable Twister – (ATM – 100)

Description

The Automatic twisting machine offers virtually double the production efficiency without any reduction in processing quality. And with its small footprint, it takes up hardly any space at all. It calculates the length automatically and in conjunction with the flat gripper option, can be used to twist two wires. The intuitive software which is operated with touch screen enables you to save the twisting parameters.

Features
  • Simple, intuitive lines in a single machine
  • Single twisting lines in a single machine
  • High production speed with one operator
  • Process parameters calculated in relation to final product
  • Networking possibilities with MIKO
  • Stringent quality assessments before production approval
  • Outstanding processing quality
  • Reliable results at all times
Applications

The End Twisting machine – (ATM-100) is used wire harness industry & house wiring.

Technical Details
Wire Type Pvc, Solid Core, Single Stranded & Rubber wires
Cable Size (Twisting) 0.2- 1.5 sqmm
Maximum Stripping length 15.0 mm
Length Accuracy ±0.2MM ( L x 0.04%) Depends on the materials
Noise Level < 70 db
Air supply 5.0-6.0 bar Dried and filtered air
Power Supply 90 W
Function Mode Foot Pedal
Dimensions (L x W x H) 300 x 220 x 310 mm
Net Weight 8 kgs
Voltage AV 220V
